Product Introduction

Functional Features

1. High-performance sensor paired with energy-efficient laser module delivers stable, millimeter-accurate depth maps.

2. AI-hardware core supports custom deep learning algorithm models.

3. Factory-calibrated internal parameters with multi-platform SDK for swift secondary development.

4. Compact size and flexible installation accommodate diverse scenarios.

5. Equipped with narrow-band filters to withstand ambient light interference.

6. Gigabit network interface ensures stable and reliable connectivity.

Ordering Model

MV-DB300S-V

*Product specifications may vary due to environmental factors. The company assumes no liability for any resulting consequences.

Dimensions

Specifications

Model	Model	MV-DB300S-V
Model	Name	Single DOE Diffractive Structured Light 3D Camera (for small volume measurement)
Performance	Near Field:	325 mm × 320 mm
	Far Field	1850 mm × 1600 mm
	Clearance Distance (CD)	300 mm
	Measurement Range (MR)	1200 mm
	Depth Detection Accuracy	X,Y:5 mm@1 m;10 mm@2 m Z:10 mm@1 m;20 mm@2 m
	Color Detection Accuracy	X,Y:2.6 mm@1 m;5.5 mm@ 2 m
	Scanning Frame Rate	Depth map: Max 17 fps @ 1280 × 1024 RGB map: Max 17 fps @ 1536 × 1280 Depth map + RGBD synchronous output: Max 14 fps @ 1280 × 1024
	Data Type	Original image (black and white + color), rectified image (left/right), depth map
	Laser Safety Class	Class 1
Electrical Characteristics	Data Interface	Gigabit Ethernet(1000Mbit/s)
	Digital I/O	6-pin M8航空头接口提供供电和I/O,1路光耦隔离输入(Line 0),1路光耦隔离输出(Line 1),1路可配I/O(Line2)
	Power Supply	12 ~ 24 VDC
	Typical Power Consumption	5.5 W@12 VDC
Structure	Dimensions	98.5 mm × 55.5 mm × 33 mm
	Weight	Approximately 200g
	IP Protection Rating	IP40
	Temperature	Operating temperature 0 ~ 45°C; Storage temperature -30 ~ 80°C
	Humidity	20% ~ 85%RH, no condensation
General Specifications	Software	HiViewer
General Specifications	Operating System	Windows 7/10/11 32/64bits
