Product Introduction

Key Feature

The devices with PRO version and MAX version support waterproof connector.

The devices with PRO version and MAX version adopt precision temperature control design for fast heat balance.

The color devices with PRO version and MAX version support auto color correction based on multi-spectral fusion technology.

The device with MAX version integrates lens and light source, enabling lens focusing and light source control.

Adopts GigE interface and max. transmission distance of 100 meters without relay.

Compatible with GigE Vision V2.0 Protocol, GenlCam Standard, and third-party software based on the protocol and standard.

Available Model

MV-CT032G-38GM01-BASE

Product detailed parameters

External Dimensions


Specifications

Model	Product Model	MV-CT032G-38GM01-BASE
Model	Type	3.2MP Area Scan Camera, 3rd Gen., GigE, Mono, BASE
Performance	Sensor type	CMOS, global shutter
	Sensor model	Stacked BSI
	Pixel size	3.45 μm × 3.45 μm
	Sensor size	1/1.8"
	Resolution	2048 × 1536
	Max. frame rate	39 fps @ 2048 × 1536 Mono 8
	Dynamic range	73.9 dB
	SNR	42.4 dB
	Gain	High full well capacity: 0 dB to 12.8 dB High sensitivity: 0 dB to 24 dB
	Exposure time	High full well capacity: 30 μs to 10 sec High sensitivity: 5 μs to 10 sec
	Exposure mode	Off/Once/Continuous exposure mode, supports Trigger Width and Trigger Controlled
	Mono/color	Mono
	Pixel format	Mono 8/10/10Packed/12/12Packed
	Binning	Supports 1 × 1, 2 × 2, 4 × 4
	Decimation	Supports 1 × 1, 2 × 2, 4 × 4
	Reverse image	Supports horizontal and vertical reverse image output
Electrical feature	Data interface	Gigabit Ethernet (1000 Mbit/s), compatible with Fast Ethernet (100 Mbit/s)
	Data interface type	RJ45 connector
	Control interface	Not support
	Digital I/O	8-pin M8 A-Code aviation connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
	Power supply	9 VDC to 24 VDC, supports PoE
	Power consumption	Typ. 1.5 W @ 12 VDC
Mechanical	Lens mount	C-mount
	Dimension	29 mm × 29 mm × 42 mm (1.1" × 1.1" × 1.7")
	Weight	Approx. 116 g (0.3 lb.)
	Ingress protection	IP40 (under proper lens installation and wiring)
	Temperature	Working temperature: –30 °C to 60 °C (–22 °F to 140 °F) Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
	Humidity	20% RH to 95% RH (no condensation)
General	Client software	MVS or third-party software meeting with GigE Vision Protocol
	Operating system	32/64-bit Windows 7/10, 64-bit Windows 11, 32/64-bit Linux
	Compatibility	GigE Vision V2.0, GenICam
	Certification	CE, RoHS, KC
